| Article no. | Version | Output | Openings across flats | Total length | Drive | ||
|---|---|---|---|---|---|---|---|
|
4550 | Injection line wrench 4550 ∙ Square, hollow 10 mm (3/8 inch) ∙ Outside 12-point profile ∙ 17 | Outside 12-point profile | 17 | 115 | j 10 = 3/8″ | |
|
4550-1 | Injection line wrench 4550-1 ∙ Square, hollow 12.5 mm (1/2 inch) ∙ Outside 12-point profile ∙ 17 | Outside 12-point profile | 17 | 120 | j 12,5 = 1/2″ | |
|
4550-2 | Injection line wrench 4550-2 ∙ Square, hollow 12.5 mm (1/2 inch) ∙ Outside 12-point profile ∙ 19 | Outside 12-point profile | 19 | 119 | j 12,5 = 1/2″ | |
|
4550-3 | Injection line wrench 4550-3 ∙ Square, hollow 10 mm (3/8 inch) ∙ Outside 12-point profile ∙ 17 | Outside 12-point profile | 17 | 83 | j 10 = 3/8″ | |
|
4550-5 | Injection line wrench 4550-5 ∙ Square, hollow 12.5 mm (1/2 inch) ∙ Outside 12-point profile ∙ 14 | Outside 12-point profile | 14 | 119 | j 12,5 = 1/2″ | |
|
4550-21 | Injection line wrench 4550-21 ∙ Square, hollow 12.5 mm (1/2 inch) ∙ Outside 12-point profile ∙ 21 | Outside 12-point profile | 21 | 91 | j 12,5 = 1/2″ |
Injection line wrench
∙ Square, hollow 12.5 mm (1/2 inch) ∙ Outside 12-point profile ∙ 14-
Article no.:
4550-5
Product information
Application:
For injection lines Ä 14 mm
- The special design of the socket ensures the injection line screw connection is properly accommodated
- FIAT ∙ CITROËN ∙ PEUGEOT ∙ RENAULT and IVECO models with Common Rail engines
- Injection line screw connection e.g. on BMW ∙ MERCEDES-BENZ ∙ VW
- Also suitable for operation of the exhaust temperature sensor on VAG diesel engines starting from Euronorm 6
- Long style
- j Drive 12.5 = 1⁄2"
- Open 12-Point Socket for the operation of screwed connections on injection lines
- The torque-controlled screw tightening required by the manufacturer can be achieved by using a HAZET torque wrench (observe manufacturer specifications)
- Surface: chrome-plated
- Made in Germany
- Wrench size: 14
- Total length: 119 mm
- Drive: Square, hollow 12.5 mm (1/2 inch)
- Output: Outside 12-point profile
- Diameter d1 (output side): 27 mm
- Diameter d2 (drive side): 22.9 mm
