| Article no. | Version | Output | Drive | Diameter d1 (output side) | Hinge / bent shape | ||
|---|---|---|---|---|---|---|---|
|
4766 | Spark plug wrench 4766 ∙ Square, hollow 10 mm (3/8 inch) ∙ Outside hexagon profile ∙ 16 | Outside hexagon profile | j 10 = 3/8″ | 21.4 mm | With hinge - for working in areas with restricted access and for getting around obstructive edges | |
|
4766-1 | Spark plug wrench 4766-1 ∙ Square, hollow 10 mm (3/8 inch) ∙ Outside hexagon profile ∙ 16 | Outside hexagon profile | j 10 = 3/8″ | 21.4 mm | With hinge - for working in areas with restricted access and for getting around obstructive edges | |
|
4766-2 | Spark plug wrench 4766-2 ∙ Square, hollow 10 mm (3/8 inch) ∙ Outside 12-point profile ∙ 14 | Outside 12-point profile | j 10 = 3/8″ | 18 mm | - | |
|
4766-3 | Spark plug wrench 4766-3 ∙ Square, hollow 10 mm (3/8 inch) ∙ Outside 12-point profile ∙ 14 | Outside 12-point profile | j 10 = 3/8″ | 19.1 mm | With hinge - for working in areas with restricted access and for getting around obstructive edges |
Spark plug wrench
∙ Square, hollow 10 mm (3/8 inch) ∙ Outside hexagon profile ∙ 16-
Article no.:
4766-1
Product information
Application:
Installing and removing spark plugs (16 mm or 5⁄8″)
- With fixing clamp for a firm hold of the spark plugs
- On e.g. VW ∙ AUDI ∙ SEAT ∙ ŠKODA ∙ RENAULT ∙ FIAT ∙ FORD ∙ OPEL/VAUXHALL ∙ BMW ∙ NISSAN ∙ HONDA ∙ MAZDA ∙ MITSUBISHI ∙ KIA ∙ Volvo
- American dimensions
- With hinge - for working in areas with restricted access and for getting around obstructive edges
- Drive with ball race
- Surface: chrome-plated
- Made in Germany
- Wrench size: 16 ∙ 5/8
- Total length: 270 mm
- Drive: Square, hollow 10 mm (3/8 inch)
- Output: Outside hexagon profile
- Diameter d1 (output side): 21.4 mm
- Diameter d2 (drive side): 18 mm
- Net weight: 0.26 kg
Stainless and insensitive to heat
Largest possible clearance of insulator
6 spring elements – firm hold of the spark plug
Damping of transverse motion
