Hazet 4812N-1AS Flexible probe, 6 mm ∅

Price : Rp 0

Availability:In stock

Deskripsi

Qty:

Article no.	Version	Diameter	Total length
4812N-1S	Semi-flexible probe, 3.9 mm ∅ 4812N-1S	3.9 mm	1000
4812N-1F	Semi-flexible probe, 3.9 mm ∅ 4812N-1F	3.9 mm	1000
4812N-1AF	Flexible probe, 6 mm ∅ 4812N-1AF	6 mm	1000
4812N-1AS	Flexible probe, 6 mm ∅ 4812N-1AS	6 mm	1000
4812N-5.5	Flexible probe, 5.5 mm ∅ 4812N-5.5	5.5 mm	1000
4812-16	Probe for video borescope 4812-16	4.9 mm	1000
4812-10/4S	Video borescope 4812-10/4S ∙ Number of tools: 4	-	-
4812N-10/3AF	Video borescope with new swivelling probe 4812N-10/3AF ∙ Number of tools: 3	-	-
4812-30	Probe adapter 4812-30	-	-
4812N-2AF	Probe for video borescope 4812N-2AF	4.5 mm	-
4812-20	Probe adapter 4812-20	-	-

6 mm ∅
Bending range: 2 x 150°, bending radius: approx. 48 mm
Probe tip may be fixed in position
Probe tip: IP 67
Viewing direction of the camera: 90° (Side-View)
no margins in view
Luminous source: 1 LED in 90° direction
For probes with new, improved connection (4812 N) to be used in conjunction with the operating panels of the sets 4812-10/4 S ∙ 4812-1/7 ∙ 4812-1/6 ∙ 4812-1/8
For connection with older operating panels, please use the adapter 4812-30
Camera resolution: 325 (H) x 250 (v) = 76800 pixels
Aperture angle of the camera: horizontal 46°, vertical: 34°, diagonal: 56°
Depth of field: 10 to 60 mm
Probe length: 1000 mm
Weight: 220 g
Total length: 1000 mm
Diameter: 6 mm
Net weight: 1.36 kg
Temperature range: 0°C – 55°C
